Vauxhall Easytronic Gearbox Clutch Actuator transmission problems

Vauxhall Easytronic clutch actuator fault

No start and 'F' on the dash



This Vauxhall Easytronic gearbox clutch actuator control module is a very common fault for Vauxhall's with Easytronic transmission. When this actuator fails the letter ‘F’ will be displayed on the dash and the vehicle will not start.

We are currently rebuilding customers own units within 2-3 working days and providing a Lifetime warranty*



Due to the fact that these units are electronically coded to your vehicle we are not able to supply a replacement unit as it would prevent your car from running, for this reason a second-hand part would not work either.





Common Failure symptoms:

  • ‘F’ warning on display
  • No start



Common fault codes:

  • P1607 – Clutch actuator malfunction / position control error
  • P1732 – Gearbox parameters limit reached
  • P1735 – Gearbox parameters not learned



Affected Vehicles:



Common failing part numbers:

  • 9126186
  • 0132900002
  • 1208067
  • AG9D300711A
  • GID300607A

(This is a very small selection of part numbers – please select your model above for more information)



Test and rebuild:

Each Vauxhall Easytronic clutch actuator is rigorously tested on our bespoke Easytronic gearbox testing rig both before and after rebuild to ensure that the actuator meets OEM specifications. During rebuild only the highest rated components are used to comply with our lifetime warranty standards.



Programming:

During test and rebuild all programming is retained – no need for coding when you receive the clutch actuator back from us.



Warranty:

Lifetime unlimited mileage*



How do I get my unit rebuilt?

To pay for the rebuild select your model above and then click: Get yours rebuilt

Print the payment/booking confirmation email.

Package the Vauxhall Easytronic clutch actuator inside a sturdy box with plenty of packaging material (make sure you include your confirmation email in the box).

Send us your package by tracked courier (the shipping instructions are on the confirmation email).

Once received we will test, rebuild and return your clutch actuator with an unlimited mileage lifetime warranty. (if your unit turns out not to be faulty then we will refund your payment less a small testing fee and return shipping)



What if I don’t want to pay up front?

This is not a problem, if you prefer this option then follow the following steps:

Fill in and submit this test form.

Print the booking confirmation email.

Package the Vauxhall Easytronic clutch actuator inside a sturdy box with plenty of packaging material (make sure you include your confirmation email in the box).

Send us your package by tracked courier (the shipping instructions are on the confirmation email).

Once received, we will test your clutch actuator and call you to advise on the outcome of testing, if your actuator is faulty and you choose to go ahead with the rebuild then we will take payment over the phone using a debit/credit card.

We will then rebuild your clutch actuator and return it to you with an unlimited mileage warranty.

If you require further information regarding this Vauxhall Easytronic clutch actuator, then please contact us.

Vauxhall Products/Services

ADAM

AGILA

ANTARA

ASTRA

COMBO

CORSA

FRONTERA

INSIGNIA

MERIVA

MERIVA A

MOKKA

MOVANO

OMEGA

SIGNUM

TIGRA

VECTRA

VIVARO

VX220

ZAFIRA

Comments on "Vauxhall Easytronic Gearbox Clutch Actuator transmission problems"
Nenad Tasic says: 11/11/2019 11:41:47 PM
I have Opel Meriva 1.6 with automatic transmission. I have all symptoms that are mentioned here. Is this part same with Vauxhall one?
ECU Admin says: 12/11/2019 2:02:42 PM
Hi Nenad, Vauxhall and Opel are the same manufacturer, just named differently based on your country. We can certainly help you out, please see the following for more information: https://www.ecutesting.com/common-faults/vauxhall/meriva-16-18-easytronic-clutchgearbox-actuator/
Terence Pope says: 31/10/2019 6:41:08 AM
Hi I have this problem 2007 zafira semi auto-How much do you charge for re-con gearbox rebuild? And of course can you ship it?to me,
ECU Admin says: 6/11/2019 3:04:19 PM
Hi Terence, we offer a rebuild service on the Zafira clutch actuator, but do not offer mechanical services such as gearbox rebuilds. For more information, prices and shipping please see the following page: https://www.ecutesting.com/common-faults/vauxhall/zafira-easytronic-clutchgearbox-actuator/
Mark Dunsmore says: 28/10/2019 12:16:52 PM
My clutch activator unit is got a malfunction on my astra wondering how to get it repaired
ECU Admin says: 6/11/2019 3:50:58 PM
Hi Mark, for information on Vauxhall Astra clutch actuators please see the following link: https://www.ecutesting.com/product-catalogue/vauxhall/astra/ecu-transmission-combined-clutch-actuator/
David morton says: 1/9/2019 2:56:27 PM
I have a 56 plate 1.8 semi auto the car will drive and change gear but then encounters problems it flashes f and you can't select neutral or any gears
ECU Admin says: 2/9/2019 9:40:28 AM
Hi David, sounds like you may have the common clutch actuator fault. We can test and rebuild this for you, just select your vehicle above or complete our test form to begin the process: https://myaccount.ecutesting.com/?return=/TestForm&lang=en-GB
